product description
NEW OEM REPLACEMENT FOR CHAR-LYNN 113-1077-006 MOTOR
Form, fit, and function the same, at a substantial savings
All units are TESTED same day prior to shipment, and come complete with a 2-year warranty
Item is in stock, ships same day with an order placed by 2pm EST. Repair parts also in stock
Questions? Give us a call 24hrs a day 1-877-FLUIDPOWER
--------------------------------------------------------------------------------
Specifications:
OEM Char-Lynn 6000 Series
DISPLACEMENT: 15.04 in3/r [246.5 cm3/r]
SHAFT: 38.10 [1.500] DIA. FLAT ROOT SIDE KIT; 17 TOOTH; 12/24 DP 30 DEG. INVOLUTE SPLINE WITH .375-16 UNC-2B THREAD IN END 40.4 [1.59] MINIMUM FULL SPLINE LENGTH
MOUNT: WHEEL; 4 BOLT; 5.50 [139.7] PILOT DIA. .565 [14.35] DIA. HOLES ON 7.25 [184.2] DIA. BOLT CIRCLE
PORT SIZE: 1.3125-12 UN-2B SAE O-RING PORTS - STAGGERED PORTS
--------------------------------------------------------------------------------
Data Sheets
